Leírás
AP2-1 Current Loop unit 4–20 mA has been designed to convert digital value of mass to analog value. It is a unit of passive type, i.e. it requires to be supplied with power from an external source, of 24 VDC voltage value.
AP2-1 Current Loop unit indicates mass as:
absolute value (no sign),
positive values exclusively,
mass value with sign.
The AP2-1 is intended for cooperation mainly with scales operated via PUE C315 and PUE 7.1 indicators. It is housed in a plastic casing, and powered with power supply 230V/5VDC. The AP2-1 and the power supply are sold as a set. The current circuit is led through 1.7-meter-long cable.
Parameters
- Net weight: 0,4 kg
- Gross weight: 0,8 kg
- Packaging dimensions: 220×190×90 mm
